Raspberry Pi 3 Model B
Read SolutionImplemented by
Raspberry Pi Foundation
Updated on June 16, 2024
·Created on September 8, 2017
Combination of freely available software and content modules that enable online educational materials into places with limited or no internet access
RACHEL, the Remote Area Community Hotspot for Education and Learning, is a combination of freely available software and content modules that enable online educational materials into places with limited or no internet access. The content is available in multiple languages and can be customized to suit local needs.
It is divided into two areas:
– RACHEL Content Library, which can be installed and deployed freely and everywhere by downloading content from their site
– RACHEL Hardware, a hardware, pre-installed with the most-used RACHEL content.
Target SDGs
SDG 9: Industry, Innovation and Infrastructure
SDG 4: Quality Education
Market Suggested Retail Price
$749.00
Target Users (Target Impact Group)
Household, Community
Distributors / Implementing Organizations
World Possible.
Competitive Landscape
Direct competitors include Kiwix and Internet-in-a-box.
Regions
Worldwide
Manufacturing/Building Method
RACHEL Content Library is developed mainly with Shell, PHP and Perl.
The RACHEL-Pi is based on the Raspberry Pi 3 Model B.
Intellectural Property Type
Open-source
User Provision Model
RACHEL Content Library is provided through their GitHub site and FTP site.
RACHEL Hardware can be purchased through the project's web page.
Distributions to Date Status
Rachel is used by hundreds of partner organizations in over 40 countries worldwide
Type of service
Provides content and information for off-grid networks.
Telecommunication service required
Local wired or wireless connection required for end-users to access content repositories.
Fixed network connection required (Y/N)
No.
Additional device required
To be accessed it requires users to have a devices such as smartphone or personal computer. If deployers do not get RACHEL Hardware a server in which content will be installed is required.
Two way communication (Y/N)
Yes.
Battery life (hours)
For RACHEL Content Library it does not apply. For RACHEL Hardware there are differentiated attributes for every product.
Network capacity
Power requirements
Power requirements will depend on selected hardware applied to install solution.
Average packet loss
N/A
Application
Education.
Design Specifications
RACHEL-Corrections 3.0
- Required skills: None
- Number of simultaneous users: 20-50
- Supported content storage: 500GB HDD
RACHEL-Plus
- Required skills: None
- Number of simultaneous users: 10-50
- Supported content storage: 500GB HDD
RACHEL-Pi
- Required skills: SSH or linux command line for safe shutdown (recommended)
- Number of simultaneous users: 1-10
- Supported content storage: 64GB
Technical Support
There is an open community for support and a side community called RACHEL Friends that aims to improve, expand, spread, and document RACHEL, the best ways use it, and experiences deploying it.
Replacement Components
For RACHEL Content Library it does not apply.
For RACHEL Hardware there are differentiated policies for every product.
Lifecycle
For RACHEL Content Library it does not apply.
For RACHEL Hardware this is unknown.
Manufacturer Specified Performance Parameters
Vetted Performance Status
Results of an independent evaluation of the Sergio Paiz Andrade Foundation’s (Funsepa) pilot program in Sacatepéquez presented in this report. The pilot aimed to take an innovative approach to Funsepa’s traditional programming and enhance student academic performance in mathematics. The results show that consistently, students with access to e-education resources scored more than 10% that their control group counterpart. An independent evaluation of The Samuel Morris Scholar’s Pilot Program initiated by Innovative Education Liberia (IEL) in a remote, rural county of Liberia during the 2015-2016 academic year show that, relative to the comparison group, the pilot intervention leads to an average increase of 10 points in math scores, out of a maximum possible score of 100 points, which is double the increase of five points produced by Funsepa’s traditional program.
Safety
N/A
Complementary Technical Systems
None.
Academic Research and References
“World Possible’s RACHEL Server – The Best of the Web Offline.” n.d. World Possible. Accessed June 16, 2024. https://worldpossible.org/
“RACHEL-Plus 4.0 ($500).” n.d. World Possible. Accessed June 16, 2024. https://racheloffline.org/collections/frontpage/products/rachel-plus
“RACHEL-Plus 4.0 ($500).” n.d. World Possible. Accessed June 16, 2024. https://worldpossible.org/products/rachel-plus
“Goal 9.” n.d. Sdgs.Un.Org. Accessed June 16, 2024. https://sdgs.un.org/goals/goal9
Rachel-Web: Code for RACHEL Content Website. n.d. Accessed June 16, 2024. https://github.com/worldpossible/rachel-web
“World Possible’s RACHEL Server – The Best of the Web Offline.” n.d. World Possible. Accessed June 16, 2024. https://racheloffline.org/
“World Possible Community.” n.d. World Possible Community. Accessed June 16, 2024. https://community.worldpossible.org/
N.d. Learningequality.Org. Accessed June 16, 2024. https://learningequality.org/media/FUNSEPA_Final_Evaluation_Report_27May2016.pdf
Compliance with regulations
Yes. All content available within RACHEL solution is open source and can be freely share everywhere.
Evaluation methods
For verification of proper hardware and software installation, an operation test on connectivity and data accessibility must be performed.
Other Information
There are video-tutorials on the Jeremy Schwartz YouTube Channel.
